Connector J2-5, 6, 7

This set of pins constitutes the main power connection for the

ProComm.

Connector J3-5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15, 16

Connector J3 is the interface for the 8 relay outputs of the ProComm. All

relays are independent and can be configured as either normally open

(n/o) or normally closed (n/c). All relays are rated at 6 amps continuous

duty.

Output

Number

Common

Contact Pin

(n/o or n/c)

1 J3-1 J3-2

2 J3-3 J3-4

3 J3-5 J3-6

4 J3-7 J3-8

5 J3-9 J3-10

6 J3-11 J3-12

7 J3-13 J3-14

8 J3-15 J3-16

J2-5

Power supply input of Hot (120VAC operation) or Line

(220VAC operation).

J2-6 Power supply input of Neutral (120VAC operation) or

Line (220VAC operation).

J2-7 Power supply earth/chassis point. Connect for point

of reference and path of noise suppression.
